MS27200A
Microwave Spectrum Monitor Module
Small form factor for easy integration into various platforms and systems, fast development, no need to develop a spa, perfect for SIGINT, TSCM, interference hunting, and drone detection applications
Frequency Range: 9 kHz to 9/14/20/26.5/32/43.5/54 GHz
The Anritsu MS27200A Microwave Spectrum Monitor Module represents decades of experience in spectrum analysis that can be integrated into any system. It has advanced built-in capabilities such as 5G, LTE, AM/FM, WCDMA, RTSA, and IQ capture and streaming. The module can perform a multitude of measurements without the need for an external PC to process the trace data. All communication is done via SCPI commands.
The MS27200A provides the top-tier RF performance for any system. With a displayed average noise level (DANL) of -164 dBm and Third-Order Intercept (TOI) of +20 dBm (typical), it provides top-level accuracy performance out of your spectrum analyzer. Providing top-level accuracy performance out of your spectrum analyzer. The module has up to 110 MHz analysis bandwidth, providing a powerful RTSA and the ability to capture large bandwidth signals.
The small form factors allow it to be easily integrated into various platforms and systems. The module allows for fast development without the need to develop a spectrum analyzer. Perfect for any SIGINT, TSCM, interference hunting, or drone detection application.
